Intel Edge Platform

System Processor

CPU	Intel® Processor N150 4-core processor up to 3.60 GHz Intel Atom® x7433RE 4-core processor up to 3.40 GHz Intel® Core™ 3 Processor N355 8-core processor up to 3.90 GHz
Memory	1 x DDR5-4800 SO-DIMM up to 16GB
Graphics	Intel® Graphics
Watchdog	Auto reset for unresponsive system (custom 1-255 sec/min delay settings in BIOS)
Security	TPM 2.0

Internal Expansion

M.2	1 x M.2 3042/3052 Key B for WWAN w/ Nano SIM support 1 x M.2 2230 Key E for Wi-Fi/BT

Power

Power Input	DC 9-36V (nominal power input DC 12V/24V) via 2-pin terminal block
Power Protection	OCP, OVP, surge protection, reversed polarity protection

Storage

Type	1 x 2.5” SATA SSD 1 x M.2 2242 Key B for SATA SSD * M.2 Key B is a combo slot, either WWAN module or M.2 SATA can be installed.

Software

Operating System	Windows 11 IoT Enterprise LTSC Ubuntu 24.04 LTS

Interface

Video	2 x HDMI® up to 3840 x 2160 @ 60Hz as specified in HDMI 2.0b
Audio	1 x Line-out, 1 x Mic-in
Ethernet	2 x 2.5GbE (Intel I226-LM) via RJ-45
USB	2 x USB 3.2 Gen 1 4 x USB 2.0
DIO	4 x DI (DC 5-36V) 4 x DO (DC 5V/100mA)
COM	2 × RS-232/422/485 2 × RS-232 (Optional)

Mechanical

Construction	Aluminum Alloy
Antenna	4 x SMA connector mounting hole
Mounting	DIN rail, Wall, VESA mounting
Net Weight	1.2kg (2.64 lb)
Dimensions (L x W x H)	150 x 106 x 55 mm (5.91 x 4.17 x 2.17 in.)

Environment

Operating Temp.	-40°C ~ 70°C (-40°F ~ 158°F) with 0.6 m/s airflow
Storage Temp.	-40°C ~ 80°C (-40°F ~ 176°F)
Relative Humidity	10% RH ~ 90% RH (non-condensing)
Certification	CE, FCC Class A, UKCA, IEC/EN 62368-1

Ordering Information

Mode Number	RMC-A2625-N150, RMC-A2625-N355, RMC-A2625-x7433RE
Description	RMC-A2625-N150 Intel® Processor N150 w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer RMC-A2625-N355 Intel® Core™ 3 Processor N355 w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer RMC-A2625-x7433RE Intel Atom® x7433RE w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer
